HPE Networking Instant On Secure Gateway SG1004 4-Port 1G Smart-managed Gateway, 4x 1GBase-T, US Cord

Product information "HPE Networking Instant On Secure Gateway SG1004 4-Port 1G Smart-managed Gateway, 4x 1GBase-T, US Cord"

The HPE Networking Instant On Secure Gateway is a powerful, cloud-managed security solution designed for small and growing businesses. It delivers enterprise-grade security—firewall, IDS/IPS, VPN, PoE, and WAN resiliency—without hidden fees or licenses. Managed through a single platform, it offers domain blocking, deep packet inspection, and 24x7 network monitoring to protect against cyberthreats. Designed with ease of use in mind, it enables minimum-touch deployment and automated configuration, making network setup and management accessible even for non-technical users. Ideal for securing customer data, transactions, and multi-site connectivity, this gateway provides easy, reliable control tailored to SMB needs, combining simplicity with top-tier protection.

The HPE Networking Instant On Secure Gateway SG1004 is a 1 G secure gateway featuring one uplink (WAN) port, two downlink (LAN) ports, and one configurable uplink/ downlink port. With a stateful firewall throughput of 930 Mbps, it is ideal for protecting businesses with less than one Gigabit total throughput from their ISP. The compact design and external power supply make it perfect for branch offices or small businesses like accounting firms or retail shops.

What's New

  • Cloud-based management: Seamless remote monitoring and management controls through centralized Instant On Cloud Portal/app; automated firmware updates delivered through the cloud.
  • Secure the LAN: Implementation of Zero Trust model architecture and enhanced hardware-accelerated firewall features keep your business safe.
  • WAN redundancy and load balancing: Automatically selects the most optimal WAN connection when multiple ISP connections are detected for uninterrupted internet access.
  • Enhanced user experience: Improved and more intuitive design for simplified navigation and user experience.
  • PoE+ support (SG2505P): Up to 60W of Power over Ethernet (PoE) budget for simplified device deployment.
  • Multi-gigabit WAN support (SG2505P): New multi-gigabit WAN ports for faster and more reliable connectivity.

Limited Warranty 2 Year

Total Number of Ports 4
Number of Network (RJ-45) Ports 3
Number of WAN Ports 1

Product Line Instant On
Product Model SG1004
Product Name Networking Instant On Secure Gateway
Product Type Router

Ethernet Technology Gigabit Ethernet
Network Technology 10/100/1000Base-T

Form Factor Wall Mountable
Form Factor Tabletop
Height 1.7"
Width 7.5"
Depth 6.5"
Weight (Approximate) 2.20 lb
